Suzuki LT-A50 - Engine Removal and Remounting Procedures

ENGINE 3-3
ENGINE REMOVAL AND REMOUNTING
ENGINE REMOVAL
Before taking the engine out of the frame, wash the engine using
a steam cleaner. Engine removal is sequentially explained in the
following steps.
• Drain the transmission oil. (!2-8)
• Remove the seat. (!5-2)
• Remove the frame cover. (!5-2)
• Remove the fuel tank. (!4-2)
• Remove the exhaust pipe cover.
• Remove the exhaust pipe bolts.
• Remove the muffler.
