Suzuki LT-A50 - Removal and Disassembly; Front Suspension

5-14 CHASSIS
REMOVAL AND DISASSEMBLY
FRONT SUSPENSION
• Remove the front wheel. ("5-4)
• Remove the front brake. (" 5-7)
• Remove the front brake cable 1.
• Remove the cotter pin and remove the tie-rod end nut 2.
• Remove the front suspensions arm nuts.
• Remove the front shock absorber upper bolt.
• Remove the front shock absorber and suspension arm.
• Remove the front shock absorber lower bolt 3.
• Remove the cotter pin and knuckle arm nut 4.
• Remove the dust seals and spacer.
