CHASSIS 5-13
1 Clamp
2 Handlebar
3 Steering shaft
4 Dust seal
5 Steering shaft holder
6 Steering shaft lower dust seal
7 Bushing
8 O-ring
A Handleber clamp bolt
B Steering shaft holder bolt
C Steering shaft lower nut
!
ITEM N
.
m kgf
.
m lb-ft
A 13 1.3 9.5
B 23 2.3 16.5
C 29 2.9 21
