CHASSIS 5-19
REASEMBLY AND REMOUNTING
Reassemble and remount the steering stem and front suspen-
sion in the reverse order of removal and disassembly. Pay atten-
tion to the following points.
STEERING SHAFT
• Install the steering shaft bushing using the special tool.
% 09924-84510: Bearing installer set
• Apply SUZUKI SUPER GREASE “A” to the new dust seal 1,
steering shaft holders 2 and new dust seals 3 before remount-
ing the steering shaft.
For USA
& 99000-25030: SUZUKI SUPER GREASE “A”
For the others
& 99000-25010: SUZUKI SUPER GREASE “A”
#
To prevent the entry of dirt, the dust seal end 4 must
face forward when installed on the steering shaft.
