DNX-11 Installation Proper Grounding
DOC-001-11001 (Rev. 006) 9 DNX Quick Install & Setup Guide
Proper Grounding
Grounding via Rack Mount
1. Mount the DNX to the equipment rack using rack-mounting screws as shown in Figure 7
below:
Figure 7: Properly Grounding the DNX.
Mounting
Bracket
Rack Mounting
Screw
