Install IP Address
Port IP Address Configuration
The Port Configuration Menu is used to configure the TCP/IP stack in the DNX and control its IP
address and how it behaves on your 10BaseT LAN segment. These options only affect the
10BaseT (SMC II) or 10/100BaseT (SMC IIA) port operation, they are not directly related to the
flow of user data through the DNX.
1. From the DNX Main Menu, place your cursor on the System Configuration field and press
<Enter>. The Node Configuration Menu appears.
2. From the Node Configuration Menu, place your cursor on the Port IP Addresses field and
press
<Enter>. The following screen appears.
3. Move your cursor to applicable fields to specify information on the Port Configuration Menu;
for details refer to Table 4 on the following page.
4. When configuration is complete, press
X to save and exit to the previous menu. When
prompted “Update Configuration?”, press
Y to save and exit.
Figure 30: Port Configuration Menu.
Eastern Research, Inc. DNX 11 - Node Manager Help = [?]
Port Configuration Menu
IP encapsulation.................: Ethernet II
LAN IP address...................: 0.0.0.0
LAN IP mask......................: 0.0.0.0
Enable RIP.......................: No
Default gateway (if RIP disabled): 0.0.0.0
Changes to IP encapsulation, LAN IP address or LAN IP mask
will cause open telnet sessions to be closed.
