Verifying Protection Switch Installation PSX Module Installation and Cable Connection
DOC-001-11001 (Rev. 006)
44 DNX Quick Install & Setup Guide
Verifying Protection Switch
Installation
To ensure the Protection Switch has been properly installed, verify the Card Status is Ok and
the Switch State’s condition is Normal.
Verify the Protection Switch Installation
1. From the DNX Main Menu, move your cursor to the Nest Summary field and press <Enter>
The Slot Summary Menu appears:
2. Verify that the Protection Switch is Online by looking in the device state column. Move your
cursor to the PSX field and press
<Enter>. The Protection Switch’s Main Menu appears:
Figure 31: Slot Summary Menu.
Eastern Research, Inc. DNX 11 - Node Manager Help = [?]
Standby SMC not present N+1 Redundancy State: Enabled
Alarm Contacts..: Enabled Alarm Contact Type..: Standard
Nest #1 Slot Summary Menu
N+1
Slot# Group Configured Type Device State Alarm
----- ----- --------------- ------------ -----
01 Octal T1/E1 Online None Clock Src
02 Octal T1/E1 Online None
03 Octal T1/E1 Online None
04 Octal T1/E1 Online None
05 Octal T1/E1 Online None
06 Hybrid DS-3 Online None
07 Hybrid DS-3 Standby None
08 STS-1 Online None
09 STS-1 Online None
10 Hybrid DS-3 Online None
11 Hybrid DS-3 Online None
SMCA System Manager A Standby None
SMCB System Manager B Online None
PSX ProtectionSwitch Online None
[C]lear error counts [T]oggle Alarm Contacts
N+1 Device Redundancy: Switch[O]ver [R]estore [E]xpose
