Verifying Protection Switch Installation PSX Module Installation and Cable Connection
DOC-001-11001 (Rev. 006)
45 DNX Quick Install & Setup Guide
3. Move your cursor to the Status field and press
<Enter>. The Protection Switch’s Status
Menu appears; it should look similar to the one shown in Figure 33.
Figure 32: Protection Switch Main Menu.
Eastern Research, Inc. DNX - Protection Switch Help = [?]
Main Menu
---------
Status
Utilities
About
Figure 33: Protection Switch Status Menu.
Eastern Research, Inc. DNX - Protection Switch Help = [?]
Status Menu
-----------
Slot# Card Type Card Status Switch State Switch Status
--------------------------------------------------------------------------------
01 Narrowband Redundant Ok Normal Ok
02 Narrowband Primary Ok Normal Ok
03 Narrowband Primary Ok Normal Ok
04 Narrowband Primary Ok Normal Ok
05 Narrowband Primary Ok Normal Ok
06 Broadband '2' Primary Ok Normal Ok
07 Broadband '2' Redundant Ok Normal Ok
08 Broadband '1' Primary Cable Missing Normal Ok
09 Broadband '1' Primary Ok Normal Ok
10 Broadband '1' Primary Ok Normal Ok
11 Broadband '1' Redundant Ok Normal Ok
Power Supply A Status.: Ok Fan Maintenance: Auto Fan #01: Ok
Power Supply B Status.: Fault Fan Speed......: Low Fan #02: Ok
Chassis Temperature...: 85 F/29 C Fan #03: Ok
