Verifying Protection Switch Installation PSX Module Installation and Cable Connection
DOC-001-11001 (Rev. 006)
46 DNX Quick Install & Setup Guide
To expose additional information about the Protection Switch, go back to the Nest Summary
Menu, and at the PSX field, press the
E key. The resulting screen should look similar to the one
shown in Figure 34.
The screen above shows the Protection Switch is online, and operating with the Rev 0 Control-
ler Module. In this case, the chassis is ‘Undetermined’ because a Rev 0 Controller Module
cannot determine the chassis type. In order to enable a second broadband group, you must
physically look at your PSX chassis label to find out if you have a PSX-5200 or PSX-5300 chas-
sis. Once that determination has been made, go to the Nest Profile Menu, which is displayed
on the following page. The information contained on the Protection Slot Information Display is
listed in Table 5.
Figure 34: Protection Switch Slot Information Display.
Eastern Research, Inc. DNX 11 - Node Manager Help = [?]
Protection Slot Information
----------------------------------------------- ----Major Alarms---
Device........: Online Power Supply A: Ok
Psx Controller: Rev #0 Power Supply B: Ok
Chassis.......: Undetermined Fan 1.........: Ok
Fan 2.........: Ok
Fan 3.........: Ok
PSX Interface Card Alarms
01=None 02=None 03=None 04=None 05=None 06=None
07=None 08=None 09=None 10=None 11=None
