Verifying Protection Switch Installation PSX Module Installation and Cable Connection
DOC-001-11001 (Rev. 006)
47 DNX Quick Install & Setup Guide
Table 5: Protection Slot Information Display Field Descriptions.
Field Description
Device:
(display field) Displays the state of the PSX as Online or Offline.
Psx Controller: (display
field)
Displays the revision level of the PSX Controller Module.
Chassis: (display field) Displays the type of chassis as PSX-5200 or PSX -5300.
Power Supply A or B:
(display field)
Displays the status of Power Supply A or B as one of the following:
• Ok
• Fault
Fan 1, 2, or 3: (display field) Displays the status of Fan 1, 2, or 3 as one of the following:
• Ok - Fan is operating properly.
• Fault - Fan has been shut off, or is otherwise inoperative.
PSX Interface Card
Alarms:
(display field)
Displays the status of each of the 11 slots in the PSX-5300.
