Symmetricom TimeProvider 1100 Reference Guide

Chapter 2 TL1 Command Syntax and Description
Retrieve PM (RTRV-PM)
118 TimeProvider TL1 Reference Guide 097-58001-01 Revision E – September 2006
Response Example
TIMEPROVIDER 05-02-10 13:37:39
M TP1000 COMPLD
"IOC1-GPS:FFOFF-60,-59,COMPL,05-02-03,19-00-32"
"10,-26,83,-101,-7,25,-31,-47,-32,183"
"-129,-64,-51,-27,52,-41,70,-14,-7,63"
"18,-89,-12,58,40,-101,-27,103,-4,10"
"-1,-21,-12,-4,-4,-7,15,-19,113,-66"
"42,10,-52,70,-94,22,87,-16,-74,113"
"-16,75,-51,-11,-112,220,-212,-84,107,"
;
Example
To retrieve MTIE data:
Input
RTRV-PM::IOC1-INP-2:TP1000::MTIE;
Response Format
<sid> <date> <time><cr><lf>
M <ctag> COMPLD<cr><lf>
"IOCm-INPp:MTIE-a,<monval>,<vldty>,<sampledat>,<sampletim>"<cr><lf>
"IOCm-INPp:MTIE-a,<monval>,<vldty>,<sampledat>,<sampletim>"<cr><lf>
Response Example
TIMEPROVIDER 05-02-10 13:37:39
M TP1000 COMPLD
"IOC1-INP2:MTIE-1,1,COMPL,05-02-10,12-00-00"
"IOC1-INP2:MTIE-5,3,COMPL,05-02-10,12-00-00"
"IOC1-INP2:MTIE-10,6,COMPL,05-02-10,12-00-00"
"IOC1-INP2:MTIE-50,7,COMPL,05-02-10,12-00-00"
"IOC1-INP2:MTIE-100,8,COMPL,05-02-10,12-00-00"
"IOC1-INP2:MTIE-500,10,COMPL,05-02-10,12-00-00"
"IOC1-INP2:MTIE-1000,15,COMPL,05-02-10,12-00-00"
"IOC1-INP2:MTIE-5000,15,COMPL,05-02-10,12-00-00"
"IOC1-INP2:MTIE-10000,15,COMPL,05-02-10,12-00-00"
"IOC1-INP2:MTIE-50000,20,COMPL,05-02-10,12-00-00"
"IOC1-INP2:MTIE-86400,25,COMPL,05-02-10,12-00-00"
;
Example
To retrieve PHASE data:
Notes:
This data record provides the most recent 60 seconds of phase data.
The data resolution is 100pS resolution. PHASE1S and PHASE1M
data record resolution is 1 nS.
The first line of the record has the first measurement requested, the
timestamp (<sampletim>, <sampledat>) are associated with this
measurement.
