097-58001-01 Revision E – September 2006 TimeProvider TL1 Reference Guide 93
Chapter 2 TL1 Command Syntax and Description
Retrieve Craft Data (RTRV-CRAFT)
"
RTMB-2:<rtmstatus>,<rtmstate>,<rtmlbo>,<freeflt>,<holdflt>,<rtmslip>”<cr><lf>
"
RTMC-1:<rtmstatus>,<rtmstate>,<rtmlbo>,<freeflt>,<holdflt>,<rtmslip>”<cr><lf>
"
RTMC-2:<rtmstatus>,<rtmstate>,<rtmlbo>,<freeflt>,<holdflt>,<rtmslip>”<cr><lf>
"
RTMD-1:<rtmstatus>,<rtmstate>,<rtmlbo>,<freeflt>,<holdflt>,<rtmslip>”<cr><lf>
"
RTMD-2:<rtmstatus>,<rtmstate>,<rtmlbo>,<freeflt>,<holdflt>,<rtmslip>”<cr><lf>
"
E422A:<outstatus>,<outstate>,<frmtype>,<freeflt>,<holdflt>”<cr><lf>
"
E422B:<outstatus>,<outstate>,<frmtype>,<freeflt>,<holdflt>”<cr><lf>
"
E422C:<outstatus>,<outstate>,<frmtype>,<freeflt>,<holdflt>”<cr><lf>
"
E422D:<outstatus>,<outstate>,<frmtype>,<freeflt>,<holdflt>”<cr><lf>
"
NTP:AUTHENTICATION,<authen>
"
<cr><lf>
"
NTP:SERVER,<serveripl>,<keyid>,<minpoll>,<maxpoll>,>preferred>
"
<cr><lf>
...
"
NTP:SERVER,<serveripl>,<keyid>,<minpoll>,<maxpoll>,>preferred>
"
<cr><lf>
;
Table 2-16. RTRV-CRAFT Output Fields
Field Description
<aid> = SYS
pwra
pwrb
Indicates if the IMC has detected a loss of power at the Power A(B) connection.
PWRA(B)-OK – no PWRA(B) alarm is currently active
PWRA(B)-ALM – a PWRA(B) alarm is currently active
expneqpt Indicates if the connection to the expansion output panel was lost.
EXP-OK – no EXPFAIL alarm is currently active
EXP-ALM – an EXPFAIL alarm is currently active
extalm1
extalm2
Indicates if external equipment is currently generating alarm(s).
EXT1(2)-OK – no EXTALM1(2) alarm is currently active
EXT1(2)-ALM – an EXTALM1(2) alarm is currently active
ioc1eqpt
ioc2eqpt
Indicates if the system is equipped with an IOC module in the specified slot.
IOC1(2)-EQPT – an IOC1(2)EQPT event was received
IOC1(2)-UNEQPT – no IOC1(2)EQPT event was received
sysqlevel Indicates the system output quality level (1 through 9)
lastdat The date the system was last provisioned by a user.
The format is YY-MM-DD, where YY is the 2-digit year, MM is the 2-digit
representation of the month, and DD is the day of the month.
lasttim The time the system was last provisioned by a user.
The format is HH:MM:SS, where HH is the hour in 24-hour format, MM is the minutes,
and SS is the seconds.
syncmode The TimeProvider system’s currently provisioned operating mode:
SSU | SUB | PRR
refmode The reference selection mode:
AUTO | FORCED
inpref
The input reference selected when the reference mode (REFMODE) is set to FORCED:
GPS | PRS | INP1 | INP2 | NONE
