Chapter 2 TL1 Command Syntax and Description
Retrieve PM (RTRV-PM)
Example
To retrieve FFOFF data:
Input
RTRV-PM::IOC1-GPS:TP1000::FFOFF-60;
Response Format
<cr><lf><lf>
sid date time<cr><lf>
M ctag COMPLD<cr><lf>
"IOCm-INPp:FFOFF-60,<monval>,<vldty>,<sampledat>,<sampletim>"<cr><lf>
“<.>,<.>,<.>,<.>,<.>,<.>,<.>,<.>,<.>,<.>"<cr><lf>
"<.>,<.>,<.>,<.>,<.>,<.>,<.>,<.>,<.>,<.>"<cr><lf>
Table 2-28. RTRV-PM Output Fields
Field Value Description
<aid> Specified AID used in the command.
<monval> The requested performance data (an absolute value).
<vldty>
COMPL
NA
OFF
Indicates if the data sample is considered a valid measurement by
the system.
 COMPL – Data is valid over specified time period
 NA – Data is not available
 OFF – Port is disabled
<sampledat> For Phase and FFOFF data the date represents the date of the first
data sample of the data set. For MTIE and TDEV data the date
represents the last date the data was calculated.
<sampletim> For Phase and FFOFF data the time represents the time of the first
data sample of the data set. For MTIE and TDEV data the time
represents the last time the data was calculated.
<.> A value that indicates the difference or delta from the <monval>
Notes:
To select a specific set of accumulated FFOFF-60 data from the
previous 24 hours, enter the start date (startdat), start time
(starttim), stop date (stopdat), and stop time (stoptim).
If any startdat or starttm combination is null or outside of the
previous 24-hour window, the current 1-Hour 1-Minute Fractional
Frequency Offset data is displayed.
The first line of the record has the first measurement requested, the
timestamp (<sampletim>, <sampledat>) is associated with this
measurement.
