097-58001-01 Revision E – September 2006 TimeProvider TL1 Reference Guide 79
Chapter 2 TL1 Command Syntax and Description
Retrieve BesTime Status (RTRV-BESTIME-STAT)
Retrieve BesTime Status (RTRV-BESTIME-STAT)
This command displays the BesTime status, the data indicates predicted BesTime
ensemble information.
This command has a default access level of USER.
Syntax
RTRV-BESTIME-STAT:[tid]:<aid>:[<ctag>];
Response Format
<cr><lf><lf>
sid date time<cr><lf>
M ctag COMPLD<cr><lf>
"IOCm-SYS:<tfom>"<cr><lf>
"IOCm-PRS:<prs_wt>"<cr><lf>
"IOCm-INP1:<inp1_wt>"<cr><lf>
"IOCm-INP2:<inp2_wt>"<cr><lf>
"IOCm-LO:<lo_wt>"<cr><lf>
;
Parameter Value Description
<aid> IOCm Retrieves the BesTime status of the specified Input/Output
Card module.
m = “1” for the slot marked “IOC 1" on the main shelf
m = “2” for the slot marked “IOC 2" on the main shelf
Note: See Table 2-12 for output descriptions.
Table 2-12. RTRV-BESTIME-STAT Output Fields
Field Description
tfom Time Figure of Merit, estimated 2-Sigma accuracy of the system 1PPS
prs_wt PRS Input reference weight indicates the amount of influence (weight) the PRS
reference on the system timing when the system is not referenced to GPS.
1.00 indicates only input being used
0.00 indicates input not being used at all
inp1_wt
inp2_wt
Input 1(2) reference weight indicates the amount of influence (weight) the Input 1(2)
reference on the system timing when the system is not referenced to GPS.
1.00 indicates only input being used
0.00 indicates input not being used at all
<lo_wt> LO weight indicates the amount of influence (weight) the LO stability has on the
system timing when the system is not referenced to GPS.
1.00 indicates only input being used
0.00 indicates input not being used at all
