SYSTEMA EOLO RT rev. 09ENIT04052021
SCHEDA COLLAUDO
Operation description Done Measured / set value
Bleed the gas supply line
□ YES
□ NO
---
Restore the gas supply pipe after venting and check that there are
no leaks
(use a soapy solution or equivalent product, do not use open ames)
□ YES
□ NO
---
Power the appliance electrically
(close the main switch after setting the room thermostat to the maxi-
mum temperature)
□ YES
□ NO
---
Check the direction of rotation of the fan (In the case of ap-
pliances with centrifugal fans)
If the motor runs in the opposite direction, disconnect the
power supply and change the order of the phases and check
the direction of rotation of the fan again
□ YES
□ NO
---
Measure the electrical absorption of the motor / s
□ YES
□ NO
________ [A]
Is the electrical absorption of the motor (s) within the plate
data?
□ YES
□ NO
---
Check the tensioning of the belts in the case of fans with belt
transmission
□ YES
□ NO
---
After the pre-wash time, does the ignition spark occur?
□ YES
□ NO
---
Check the intervention of the Ts / Tso thermostat protection (*).
(Disconnect the power supply and temporarily remove fuses F1 and
F2, then start the appliance to check. The fuses must be replaced
once the intervention of the Ts / Tso thermostat has been veried)
□ YES
□ NO
---
In the case of devices supplied without fans, check the settings of the
Ts / Tso thermostat for the external fan and the temperature increase
on the exchanger.
Intervention values set on Ts / Tso thermostat
Overtemperature = approx. 100 ° C Fan on = approx. 60 ° C Fan o
= 40 ° C
□ YES
□ NO
Overtemperature ______ [°C]
Ignition V. ______ [°C]
Turn o V. ______ [°C]
Does the ignition of the ame take place?
(After the third failed ignition attempt, the appliance locks up. After
10 seconds, the appliance can be unlocked by resetting the burner
control box).
□ YES
□ NO
---
5. PUT IN ACTION
(*) The intervention of the thermostat Ts causes the appliance to stop, to restart it, it is necessary to act on the reset
button (Sr). In the case of a Tso thermostat equipped with manual reset, before pressing the reset button (Sr), the
thermostat must be reset to restore operation of the appliance.
