ALGORITHMS
M5AMBIEN
Rev 1.2 Page 36
PAGE 12:
DIAL A DIAL B DIAL C DIAL D
MID-EQ2 FREQ WIDTH/SLOPE LEVEL
par.eq 19.95Hz - 20.0KHz 0.1 oct - 4.0 oct ±12 dB
notch 19.95Hz - 20.0KHz 0.02 oct - 1.0 oct 0.0dB - off
MID-EQ2 The 2nd midrange frequency filter of the 4-band equalizer. The filter
type is determined by softdial A.
PAGE 13:
DIAL A DIAL B DIAL C DIAL D
HI-EQ FREQ WIDTH/SLOPE LEVEL
par.eq 501.2Hz - 20KHz 0.1 oct - 4.0 oct ±12 dB
notch 501.2Hz - 20KHz 0.02 oct - 1.0 oct 0.0dB - off
shelve 501.2Hz - 20KHz 3/6/9/12 db/oct ±12 dB
cut 501.2Hz - 20KHz Butterw/Bessel
HI-EQ The high frequency filter of the 4-band equalizer. The filter type is
determined by softdial A.
PAGE 14:
QUANTIZ 8,12,16,18,20,22,24 bit Bit quantization of output. Select the
proper bit resolution that suits your
purpose. Dither level is automatically
adjusted to match the chosen output
resolution, but, to actually dither the
output, DITHER TYPE should be set
different from ‘none’. Please note that
the dither and quantization levels affects
both the Analog and the Digital outputs.
DITHER TYPE none, TDF, HP-TDF Dithering type selects between none
(pure truncation, w. no dither added)
TDF dither and high frequency
contoured HP-TDF dither.
