For installing 24-bit sampling, you have to place 3 modules in all three socket positions.
The SIMM-modules can only be properly inserted one way, that is with the IC's on the SIMM-
modules facing the back plate. There is an indentation (cut) on the SIMM-modules which
must be placed correspondingly with the IC16-IC18-IC17 name reference markings on the
board.
IC16 IC17
IC18
cut
