ALGORITHMS
M5ALGOIN
Rev 1.7 Page 5
Increasing the predelay will change the
apparent position and, to some degree,
the size of the room.
Max predelay before loosing taps (std. memory)
@48KHz samplerate
Size mS Size mS Size mS
Hall 0.50 112.4 1 40.7 1.28 0.0
Fan 0.50 146.8 1 109.5 2.47 0.0
Prism 0.50 135.4 1 86.7 1.89 0.0
H.Shoe 0.50 116.2 1 48.3 1.36 0.0
Club 0.50 133.4 1 82.7 1.81 0.0
Small 0.50 141.2 1 98.2 2.14 0.0
@44.1KHz samplerate
Size mS Size mS Size mS
Hall 0.50 118.2 1 52.3 1.40 0.0
Fan 0.50 149.8 1 115.5 2.69 0.0
Prism 0.50 139.4 1 94.6 2.06 0.0
H.Shoe 0.50 121.7 1 59.3 1.48 0.0
Club 0.50 137.5 1 90.9 1.98 0.0
Small 0.50 144.7 1 105.2 2.33 0.0
Max predelay before loosing taps (w.option 'himem' memory, order# 5IRAM-1)
@48KHz samplerate
Size mS Size mS Size mS
Hall 0.50 459.5 1 393.6 4.00 0.0
Fan 0.50 491.2 1 456.9 4.00 251.2
Prism 0.50 480.7 1 436.0 4.00 167.6
H.Shoe 0.50 463.0 1 400.6 4.00 26.2
Club 0.50 478.8 1 432.2 4.00 152.7
Small 0.50 486.0 1 446.6 4.00 209.9
@44.1KHz samplerate
Size mS Size mS Size mS
Hall 0.50 500.2 1 428.5 4.00 0.0
Fan 0.50 534.6 1 497.3 4.00 273.4
Prism 0.50 523.2 1 474.5 4.00 182.4
H.Shoe 0.50 504.0 1 436.1 4.00 28.6
Club 0.50 521.2 1 470.5 4.00 166.2
Small 0.50 529.0 1 486.0 4.00 228.5
table 2.
REVFEED 0.0 - 100.0 mS Sets the time before the reverberating
0.0 - 300.0 mS
2
part of the signal starts to build up,
relative to the early reflections PREDLY.
HICUT 500 Hz - flat High cut filter, shelving type. Provides
an overall reverb high frequency rolloff
(6 dB per octave) that is well suited to
make a warmer sound. Sets the cut-off
2
Only if idx RAM mounted is 64K. Check your index ram in the CONFIG menu under UTILITY.
