ALGORITHMS
M5ALGOIN
Rev 1.4 Page 6
frequency of the overall High cut filter in
1/3-octave steps.
ATT -40 - 0.0 dB The attenuation control sets the high
frequency rolloff determined by HICUT.
LO-XOVR 20 Hz - flat Sets the crossover frequency for the
x LOW decay time multiplier in 1/3-
octave steps.
HI-XOVR 20 Hz - flat Sets the crossover frequency for the
x HIGH decay time multiplier in 1/3-
octave steps.
INITLEV off - 0.0 dB. Sets the level of the initial pattern. The
purpose of this control is to balance the
initial (early) reflection levels against the
reverberating part of the reverb
algorithm.
REVLEV off - 0.0 dB. Sets the level of the reflection envelope
relative to the early reflections in 0.5 dB
steps. If REVLEV is set to
off
you will
hear only the initial reflections.
RWIDTH 0 - 100 % Sets the apparent stereo width of the
reverberating part of the algorithm. At
'0', the reverb tail will appear to be
coming mainly from the center (mono
compatible), whereas with RWIDTH set
to '100' the L/R reverberators are inde-
pendent.
I-XFEED on/off With this parameter switched off, the
cross feeds in the early reflections will
be killed. The I-XFEED switched off,
simultaneously with the parameter
RWIDTH set to 100%, will create a true
stereo reverb. The effect from the left
and the right channel will be generated
totally independent. This is ideal for
working with Dolby surround or for
broadcasting in general where mono
compatibility is important. The feature is
also especially applicable for the film
industry and post production suites.
