ALGORITHMS
M5ALGOIN
Rev 1.4 Page 14
DIFFUSE 1 - 99 The DIFFUSE parameter simulates that
the reflections in the room "hit" more or
less uneven surfaces. With smooth walls
low diffusion takes place. Walls that are
uneven, with many angles, pockets or
with dedicated diffusers cause the
reflections to break into a high number
of less identifiable reflections producing
much higher diffusion. The DIFFUSE
parameter affects the quality of the
reverb tail as well as the spread of the
initial reflections.
LO-XOVR 20 Hz - 4.00 KHz Sets the crossover frequency for the
x LOW decay time multiplier in 1/3-
octave steps. If LO-XOVR is set higher
than LM-XOVR then the LM-XOVR
frequency will change upwards.
LM-XOVR 200 Hz - 6.30 KHz Sets the crossover frequency for the
x LOMID decay time multiplier in 1/3
octave steps. If set lower than LO-
XOVR, then LO-XOVR will change
downwards.
HI-XOVR 2.00 KHz - flat Sets the crossover frequency for the
x HIGH decay time multiplier in 1/3-
octave steps.
PREDLY 1 - 150 mS or Sets the time that passes before the first
1 - 470 mS
5
reflection appear.
DISTANS 0 - 15 The relative distance control varies the
mix relations between the early and the
later reflections. When set to "0" more of
the early reflections are heard, similar to
being close to the sound source in a
room. As you increase DISTANS toward
"15" more of the later reflections are
heard = further away from the sound
source. Practically no initial reflections
are heard at "15". Please note that at very
short distances the initial reflections
5
Only if idx RAM mounted is 64K. If idx=32K, max predelay will be 150 mS. M5000 automatically checks your
hardware on power up and uses the available amount. The index ram size can be seen in the CONFIG menu
under UTILITY.
