ALGORITHMS
M5ALGOIN
Rev 1.7 Page 39
PAGE 3:
LEVEL-1 off - 0.0 dB The output level of channel 1.
PAN-1 50L - center - 50R Controls the position of channel 1 in the
stereo image.
LEVEL-2 off - 0.0 dB The output level of channel 2.
PAN-2 50L - center - 50R Controls the position of channel 2 in the
stereo image.
PAGE 4:
SPEED 0.1 Hz - 10 Hz Controls the rate of modulation sweeps
in a range from 1 sweep every 10
seconds to 10 sweeps per second.
DEPTH 0 - 100% Determines how wide a modulation
sweep is produced. If you do not want to
modulate the effect signal, set this
parameter to 0%.
PHASE 0° - 90° - 180° Determines the sine wave modulation
phase shift between left and right
channel. At 0° the left and right channel
will move in sync. At 180° the modu-
lation will move against each other.
INV PAN on/off Inverts the phase of ch.2 effect signal
panned to ch.1 output (see fig.1).
With INV PAN "on" it is possible to
make sum/difference type outputs that
work well for spatial (TC 1210 alike)
effects.
PAGE 5:
The numeric sum value of the feedback- and crossfeed parameters may not exceed 200. Any
value above 200 may cause oscillation.
FB-1 -100 - 100% The percent of positive phase and
negative phase feedback for channel 1
(feedback path includes low-cut and hi-
cut filters on PAGE 6).
FB-2 -100 - 100% The percent of positive phase and
negative phase feedback for channel 2
(feedback path includes low-cut and hi-
cut filters on PAGE 6).
XFB 1>2 -100 - 100% The percent of crossfeed from channel 1
output to ch. 2 input.
