ALGORITHMS
M5DYN
Rev 1.1 Page 10
PAGE 3:
DIAL A DIAL B DIAL C DIAL D
LO-EQ FREQ WIDTH/SLOPE LEVEL
par.eq 19.95Hz - 5.01KHz 0.1 oct - 4.0 oct ±12 dB
notch 19.95Hz - 5.01KHz 0.02 oct - 1.0 oct 0.0dB - off
shelve 19.95Hz - 5.01KHz 3/6/9/12 db/oct ±12 dB
cut 19.95Hz - 5.01KHz Butterw/Bessel
LO-EQ The low frequency filter of the 4-band equalizer. The use of this filter is
determined by softdial A.
PAGE 4:
DIAL A DIAL B DIAL C DIAL D
MID-EQ1 FREQ WIDTH/SLOPE LEVEL
par.eq 19.95Hz - 20.0KHz 0.1 oct - 4.0 oct ±12 dB
notch 19.95Hz - 20.0KHz 0.02 oct - 1.0 oct 0.0dB - off
MID-EQ1 The 1st midrange frequency filter of the 4-band equalizer. The use of
this filter is determined by softdial A.
PAGE 5:
DIAL A DIAL B DIAL C DIAL D
MID-EQ2 FREQ WIDTH/SLOPE LEVEL
par.eq 19.95Hz - 20.0KHz 0.1 oct - 4.0 oct ±12 dB
notch 19.95Hz - 20.0KHz 0.02 oct - 1.0 oct 0.0dB - off
MID-EQ2 The 2nd midrange frequency filter of the 4-band equalizer. The use of
this filter is determined by softdial A.
PAGE 6:
DIAL A DIAL B DIAL C DIAL D
HI-EQ FREQ WIDTH/SLOPE LEVEL
par.eq 501.2Hz - 20KHz 0.1 oct - 4.0 oct ±12 dB
notch 501.2Hz - 20KHz 0.02 oct - 1.0 oct 0.0dB - off
shelve 501.2Hz - 20KHz 3/6/9/12 db/oct ±12 dB
cut 501.2Hz - 20KHz Butterw/Bessel
HI-EQ The high frequency filter of the 4-band equalizer. The use of this filter is
determined by softdial A.
