3-39
Fig. 3.132
Fig. 3.135
Fig. 3.134
Fig. 3.133
■DISASSEMBLING DIFFERENTIAL
① Remove the bearing cap stopper (1).
② Remove the split pin (1) and nuts (2) and
remove the bearing cap (3).
③ Remove the cross case assembly.
④ Remove the drive pinion assembly (1).
Note: Record the type and number of shims.
To Next Page
