3-53
Fig. 3.173
Fig. 3.175
⑤ Install the nozzle (1).
⑥ Install the strainer assembly (3) using the
“O”-ring (1) and gasket (2).
⑦ Install the differential assembly on the
transmission using a new gasket.
Note: Always install the differential assembly
parallel to the transmission, aligning the
splines of the output gear with the splines
of the output shaft.
Fig. 3.174
