TCM FD35C9 - Page 243

3-129
Fig. 3.421
24
Secure the oil seal with a snap ring (1) and remove the oil seal guide.
Fig. 3.420
Cross section of
“C” lock ring
Side at which corner
is chamfered
(Front
cover)
Oil
seal
Fig. 3.422
Oil seal guide
Oil seal snap
Unit: mm [in.]
115 [4.5]
100 [3.9]
ø4 [0.16]
R2 [0.08]
R2 [0.08]
R2
[0.08]
ø4
[0.16]
ø17 [0.069]
R5 [0.2]
2 [0.06]
62 [2.44]
71 [2.8:]
92 [3.622]
22.05
[0.868 ]
+0.06
-0
+0.02
-0
23.0
+0
-0.05
[0.906 ]
+0
-0.02
23.1
+0.05
0
[0.91 ]
+0.02
0
35.5 [1.398 ]
+0.5
0
+0.02
0
