109
M_T08_EN_B
Menu: Variables
Example:
Marking carried out on Monday:
•
from 06h00 mn 00 s to 13h59 mn 59 s: "Morning"
•
from 14h00 mn 00 s to 20h00 mn 59 s: "Shift 2"
•
from 20h01 mn 00 s to 23h59 mn 59 s: "Monday evening shift"
When
deningtime
slots
for
shifts,be
careful
thatthe
shifts
do
notoverlap.
The
endof
one shift must not be the same as or later than the beginning of the next shift.
