9. O󰘯set
Used to shift the coordinates of one or more blocks.
The screen below appears:
1
2
3 4
1. O󰘯set type
2. X-Y reference coordinate(s)
3. Number of blocks involved
4. Number of markings to execute
O󰘯set type: select the required input mode.
- adjustment: de󰘰ne the new X-Y coordinates using the arrow keys on the numeric keypad.
- entry: enter the new X-Y coordinates via the keyboard at the time of marking.
- 󰘰xed: two new data entry 󰘰elds appear on the screen.
Enter the new X-Y coordinates in these 󰘰elds.
Used to specify the o󰘯set based on variable(s) by using the "Var XY" function in the preceding block.
X-Y reference coordinate(s): Xr - Yr = coordinates of the point where the stylus will be positioned - The o󰘯set
is calculated based on these coordinates.
Number of blocks involved: used to de󰘰ne the number of blocks involved in this function.
Number of markings to execute: used to de󰘰ne to how many markings this function applies.
