Technifor T08 User Manual

49
M_T08_EN_B
Menu: Edit 󰘰le
 Alignment
Used to align the text to the left, right or center.
In case of left alignment, the value of X corresponds to the beginning of the text to be marked. In case the text
is centered, the value of X corresponds to the center of the text to be marked. In case of right alignment, the
value of X corresponds to the end of the text to be marked.
In radial mode, text justi󰘰cation is done in relation to the start angle.
By default, the text is aligned to the left.
Examples
Alignment
Result
Linear marking
Angle: 0°
Linear marking
Angle: 45°
Radial marking
Clockwise marking
Left alignment
Centering
Right alignment
The X represents the start marking point (X-Y coordinates).
Thetexttobemarkedmaybecomeo󰓐-limitsiftheXorYvalue,orthecharactersize,is
too large. To correct this anomaly, reduce or increrase one or the other of these values.
