7.16 DISASSEMBLING THE LOW KIT AND POWER
ENTRY MODULE
Perform the procedures illustrated in the videos in the attached folder, according to the following
sequence:
• After removing the bottom casing as described in the video:
13 - Disassembling the bottom casing
• Proceed with:
14 - Disassembling the low kit and power entry module
7.17 ASSEMBLING THE POWER UNIT, UNTISTATIC
BRUSH AND LOW KIT
Perform the procedures illustrated in the videos in the attached folder, according to the following
sequence:
15 - Assembling the power unit, untistatic brush and low kit
7.18 DISASSEMBLING THE GRADIENT MOTOR
Perform the procedures illustrated in the videos in the attached folder, according to the following
sequence:
• After removing the bottom casing as described in the video:
13 - Disassembling the bottom casing
• Proceed with:
16 - Disassembling the gradient motor
7.19 DISASSEMBLING THE RUNNING MOTOR
Perform the procedures illustrated in the videos in the attached folder, according to the following
sequence:
• After removing the bottom casing and the slats as described in the videos:
13 - Disassembling the bottom casing
18 - Remove slats
• Proceed with:
17 - Disassembling the running motor
