7.20 DISASSEMBLING THE SLATS
Perform the procedures illustrated in the videos in the attached folder, according to the following
sequence:
18 - Remove slats
7.21 DISASSEMBLING THE REAR PULLEY
Perform the procedures illustrated in the videos in the attached folder, according to the following
sequence:
• After removing the bottom casing and the running motor as described in the videos:
13 - Disassembling the bottom casing
17 - Disassembling the running motor (ONLY belt tension release)
• Proceed with:
19 - Disassembling the rear pulley
7.22 DISASSEMBLING THE FRONT AND REAR
ROLLER
Perform the procedures illustrated in the videos in the attached folder, according to the following
sequence:
• After removing the bottom casing, the running motor and the rear pulley as described in the
videos:
13 - Disassembling the bottom casing
17 - Disassembling the running motor (ONLY belt tension release)
19 - Disassembling the rear pulley
• Proceed with:
20 - Disassembling the front and rear roller
