6.1.4.2 PROCEDURE TO FOLLOW IF THE BELTS ARE WORN BUT THE
SLATS ARE IN A GOOD CONDITION
Necessary components:
COMPONENT Q.TY
Plates (to be positioned between the slats
and the self-locking nuts)
130
Self-locking nuts 250
Strips of rubber (to be positioned between
the belt and slats)
14
Belts 2
ISOFLEX Topas L32 (45g) 1
The following components are required:
COMPONENT Q.TY
Machine lifting foot 2
M16 nut 4
Support for the equipment in a lateral po-
sition
1
M10 L75 screw 1
Number of technicians required:
2: If equipped with the accessory that blocks the equipment, when it is in a vertical
position.
3: If not equipped with the accessory that blocks the equipment, when it is in a verti-
cal position. The additional technician must keep the equipment stable when it is in
a vertical position.
Required space: 3-4 m
2
TECHNOGYM RUN Technical Service Guide
Rev. 1.0
- 59 -TSG-00284-EN- Uncontrolled copy if printed
