7.3 DISASSEMBLING THE SPEAKER CASING
Perform the procedures illustrated in the videos in the attached folder, according to the following
sequence:
1 - Disassembling the speaker casing
7.4 DISASSEMBLING THE DISPLAY
Perform the procedures illustrated in the videos in the attached folder, according to the following
sequence:
• After removing the speaker casing as described in the video:
1 - Disassembling the speaker casing
• Proceed with:
2 - Disassembling the display
7.5 DISASSEMBLING THE DISPLAY SUPPORT
Perform the procedures illustrated in the videos in the attached folder, according to the following
sequence:
• After removing the speaker casing and the display as described in the videos:
1 - Disassembling the speaker casing
2 - Disassembling the display
• Proceed with:
3 - Disassembling the display support
7.6 ASSEMBLING THE SPEAKER CASING
Perform the procedures illustrated in the videos in the attached folder, according to the following
sequence:
4 - Assembling the speaker casing
7.7 DISASSEMBLING THE CENTRAL CASING
Perform the procedures illustrated in the videos in the attached folder, according to the following
sequence:
5 - Disassembling the central casing
