6.1.4 REPLACING THE BELTS/SLATS/COMPLETE TREAD
BELT
6.1.4.1 PROCEDURE TO FOLLOW IN CASE OF WEAR OF THE BELTS
AND THE SLATS: REPLACEMENT OF THE COMPLETE TREAD
BELT
Replace the complete tread belt in the following case:
▪ Wear of the belts and the slats.
Necessary components:
COMPONENT Q.TY
Tread belt 1
ISOFLEX Topas L32 (45g) 1
The following additional components are required to install the tread belt:
COMPONENT Q.TY
Machine lifting foot 2
M16 nut 4
Support for the equipment in a
lateral position
1
M10 L75 screw 1
To facilitate the lifting of the tread belt can also be ordered the following components:
COMPONENT Q.TY
Handle 2
Safety bushings 8
Number of technicians required:
2: If equipped with the accessory that blocks the equipment, when it is in a vertical
position.
3: If not equipped with the accessory that blocks the equipment, when it is in a verti-
cal position. The additional technician must keep the equipment stable when it is in
a vertical position.
Required space: 3-4 m
