2.10 CABLES
The wiring diagrams shown above list the complete cable codes. The string xx indicates the-
generic version.
The colour of the cables may change: in particular, refer to the Pin Out.
Acronyms: GND:Ground; FC: ying connection; CN: connector
0WCU0945xx: Phase shurter cable
Plug power Signal Colour Switch ON/OFF
Faston Phase Brown Faston
Tab. 5
0WCU0946xx: Neutral shurter cable
Plug power Signal Colour Switch ON/OFF
Faston Neutral Blue Faston
Tab. 6
0WCU0947xx: Switch - Circuit breaker cable
Circuit Breaker
(L)
Circuit Breaker
(N)
Signal Colour
Switch
(L)
Switch
(N)
Faston Phase Brown Faston
Faston Neutral Blue Faston
Tab. 7
TECHNOGYM RUN Technical Service Guide
