0WCU0948xx: Circuit breaker - lter cable
Circuit Breaker
(L)
Circuit Breaker
(N)
Signal Colour
Filter
(L)
Filter
(N)
Faston Phase Brown Faston
Faston Neutral Blue Faston
Tab. 8
0WCU0967: Micro reset cable
Driver
PIN 5x2
Signal Colour
Micro Reset
COM1 NC2
1 -
2 -
3 Reference Brown Faston
from 4 to 7 -
8 Contact White or blue Faston
9 -
10 -
Tab. 9
0WCU0968xx: Drive ground cable
Ground node
(secondary)
Signal Colour Driver ground
Eyelet GND
Yellow/
Green
Eyelet
Tab. 10
TECHNOGYM RUN Technical Service Guide
Rev. 1.0
- 20 - TSG-00284-EN - Uncontrolled copy if printed
