7. PROCEDURES FOR DISASSEMBLY-
REASSEMBLY AND REPLACEMENT OF
COMPONENTS
THE DISASSEMBLE OPERATIONS ARE ILLUSTRATED ON THE VIDEOS IN AT-
TACHED TO THIS MANUAL. FOR EVERY PROCEDURE THE RELATIVE VIDEO IS
INDICATED.
The indications as tightening torques, greases, belt tension are reported on chapter $9
TIGHTENING TORQUES - GREASE - ADHESIVE & SEALANTS - BELT TENSIONING
- ADJUSTMENTS.
7.1 GENERAL INFORMATION AND WARNINGS
7.1.1 NECESSARY TOOLS
The tools required to carry out all the disassembling, adjustment and maintenance oper-
ations on the equipment are given in the TG SERVICE TOOLS BOX LIST, available on
Technogym Service Portal and during the training course on the e-learning platform.
Medium-sized Phillips screwdriver;
Small Phillips screwdriver;
Flat screwdriver;
2.5 mm - 3 mm - 5 mm - 8 mm hexagon key wrench;
13 mm open-end wrench;
Long T-handle wrench with 8 mm socket
Ratchet with 5 - 8 mm socket;
6 mm Allen wrench;
Loctite 243;
Pointed pliers;
Snap ring pliers;
Marker;
Drill with 4 mm bit;
2 x 13 mm open-end wrenches;
TECHNOGYM RUN Technical Service Guide
Rev. 1.0
- 95 -TSG-00284-EN - Uncontrolled copy if printed
