Technogym DGK02U0 - Page 24

8 nKEY_STOP_IN Yellow 12
9
VDD_12V (Led
board LEFT
Red 1
10 -
11
PWM_LED_4/
GPIO_4 (LEFT
Green 2
12 -
13
PWM_LED_8/
GPIO_8 (LEFT)
Grey 3
14
PWM_LED_12
(LEFT)
Violet/
Pink
4
from 15
to 20
-
21 REF_KEY_STOP White 1
22 nKEY_STOP_IN Blue 2
23 -
24 -
25
VDD_12V (Led
board Right)
Pink 1
26 -
27
PWM_LED_5/
GPIO_5 (Right)
Blue 2
28 -
29
PWM_LED_9/
GPIO_9 (Right)
Grey 3
30
PWM_LED_13
(Right)
Black 4
Tab. 12
0WCU1262xx: Subwoofer cable
FC 5
(to the DISPLAY)
PIN 1x2
Signal Colour Speaker Woofer
1
SPK_WOOFER_
OUTp
Red Faston
2
SPK_WOOFER_
OUTn
Black Faston
Tab. 13
TECHNOGYM RUN Technical Service Guide
Rev. 1.0
- 24 - TSG-00284-EN - Uncontrolled copy if printed
