0WCU1419xx: Extension NFC/BLE cable
Cpu Board Signal Colour NFC/BLE board
1
+5Vdc_NFC Red
1
2
rs232_NFC_TX Brown
2
3
rs232_NFC_RX White
3
4
rs232_NFC_VEN Yellow
4
5
rs232_NFC_IRQ Blue
5
6
NFC_SCL Grey
6
7
NFC_SDA Green
7
8
dgnd (NFC) Black
8
Tab. 16
0WCU1459xx: Drive power cable
Drive
PIN 2x1
Main Ground
Plug
(ground)
Signal Colour Filter
1 Phase Brown Faston
2 Neutral Blue Faston
Eyelet GND Yellow/Green Faston
Faston Faston
Tab. 17
