LEDS COLOUR STATE
UP Red ON: Upward movement (ascent) acti-
vated.
OFF: Upward movement (ascent) NOT
activated.
FLASHING: Not applicable
DOWN Green ON: Downward movement (descent)
activated.
OFF: Downward movement (descent)
NOT activated.
FLASHING: Not applicable
DC LINK Blue ON: 400V DC-Link active.
OFF: DC Link not present.
FLASHING: Not applicable.
+24 Green ON: The +24 Vdc power supply for
the gradient motor is present.
OFF: The +24 Vdc power supply for
the gradient motor is NOT present.
FLASHING: Not applicable.
+12 Green ON: The +12 Vdc Rail 1 power supply
for the display is present.
OFF: The +12 Vdc Rail 1 power sup-
ply for the display is NOT present.
FLASHING: Not applicable.
+12 Green ON: The +12 Vdc Rail 2 power supply
for the display is present.
OFF: The +12 Vdc Rail 2 power sup-
ply for the display is NOT present.
FLASHING: Not applicable.
+5 Green ON: The +5Vdc power supply for the
display is present.
OFF: The +5Vdc power supply for the
display is NOT present.
FLASHING: Not applicable.
Tab. 18
