the roller.
REAR PART FRONT PART
ADJUSTABLE
BEARING
ADJUSTABLE
BEARING
FIXED
BEARING
Fig. 28
• Check that the adjustable bearings are in contact:
_loosen the central bearing;
_check and if necessary adjust the rear bearing to bring it into contact with the belt. Tighten.
_let the central being fall onto the belt and tighten.
TECHNOGYM RUN Technical Service Guide
Rev. 1.0
- 68 - TSG-00284-EN- Uncontrolled copy if printed
