Replaceable Electrical Parts - 2230 Service
Tektronix Serial/Asssitoly No. Mfr.
Component No. P art No. E ffe c tiv e
Dscont
Name & D esc rip tion
Cafe
M fr. P art No.
A10R9211 321-0256-00
RES,FXD,FILM:4.53K OrM,1%,0.125W,TC=T9
19701
5033ED4K530F
A10RS212
311-2236-00
RES, VAR,N0NVM:TRKR,20K 0HM,20%,0.5W LINEAR
TK1450
GF05UT 2OK
A10R9213
321-0299-00 B010100
B011086
RES,FXD,FILM:12.7K OfM,1%,0.125W,TC=T0
19701 5033ED12K70F
A10R9213
321-0289-00 B011087
RES.FXD,F1LM:10.0K 0H4,1%,0.125W,TC=T0
19701 5033ED1OK0F
A10RS214
311-2234-00
RES,VAR,N0NVW:TRMR,5.< OHM,20%,0.5W LINEAR
TK1450
GF06UT 5K
A10R9219
307-0540-00
RES NTWK,FXD,FI: (5 )IK OHM,10%,0.7W
11236 750-61 -RlKOm
A10R9220
321-0197-00
RES,FXD,FILM: 1 .10K O.-M, 1%,0.125W,TC=T0
07716
CEAD11000F
A10R9221
321-0256-00
RES, FXD,FILM:4 .53K OFM,1%,0.125W,TCCT9
19701 5033ED4K530F
A10R9222
311-2236-00
RES,VAR,N0NWW:TRMR,20K 0HM,20%0.5W LINEAR
TK1450 GF06UT 2OK
A10R9223
321-0299-00 B010100
B010549 .
RES,FXD,FILM:12.7K 0rM,l%,0.125W,TG=T0
19701 5033ED12K70F
A10R9223
321-0289-00 B010550
RES, FXD, FI LM: 10. OK 0MU%,0.125W,TC=T0 19701
5O33ED1OK0F
A10R9224
311-2234-00
RES,VAR,NONVW: TRMR, 5K OHM,20%,0.5W LINEAR
TK1450 GFOSUT 5K
A10R9230
315-0122-00
RES, FXD, FI LM: 1 .2K 5%. 0 .25W
57668
NTR25J-E01K2
A10R9301
307-0446-00
RES NTWC.FXD.FI:10K OHM,20%,(9)RES 11236 750-101-R10K
A10R9302
307-0446-00
RES NTWK,FXD,FI:10K OHM,20%,(9)RES
11236 750-101-R10K
A10R9401
315-0473-00 RES,FXD,FILM:47K 0HM,5%,0.25W
57668 NTR25J-E47K0
A10R9402
315-0473-00 RES,FXD,FILM:47K OrW,5%.0.25W
57558
NTR25J-E47K0
A10R9412
311-2285-00 B010100
B012599
RES,VAR,NONWW:CCT BD.lOK 0HM,20%,0.25W
12697
CM43480
A10RT21G1
307-0124-00
RES,THERMAL:5K 0HM,20%,NTC
15454 1DC502K-220-EC
A10RT2102
307-0751-00
RES,THERMAL:20K OEM,5%
56856
QTMC-19J
A10RT2103
307-0124-00
RES.THERMAL.-5K OHM.IOX.NTC
15454
1X502K-220-EC
A10RT2111
307-0124-00
RES,THERMAL:5K OHM,1CK.NTC
15454 1DC502K-220-EC
A10RT2112
307-0751-00
RES,THERMAL:20K 0HM,5%
56866 QTMC-19J
A10RT2113
307-0124-00
RES,THERMAL:5K 0HM,10%,NTC
15454
1X502K-220-EC
A10RT2131
307-0751-00
RES.THERMAL:20K OHM,5%
56866 QTMC-19J
A10RT2132
307-0124-00 B012600
RES.THERMAL:5K OrW.lCX.NTC
15454 1X502K-220-EC
A10SS401
260-2254-00
SWITCH,PUSH:5 BUTTON.2 POLE,MEMORY
80009
260-2254-00
A10SS402
260-2253-00
SWITCH,PUSH:5 BUTTON.2 P0LE.ST0RA6E
80009 260-2253-00
A10S9403
A10S9412
260-1132-02
.................
B010100
B012599
SWITCH.PUSH:DPDT,1A,23VDC,1 BUTTON
(PART OF R9412)
59821 2KAB010000543
A1072201
120-1661-00
TRANSFORMER,RF:7 TURNS.BIFILAR,COMMON MODE
TK1345
ORDER BY DESCR
A1OT 2202
120-1680-00
TRANSFORMER,RF:5 TURN.BIBILAR
80009
120-1680-M
A10T22C3
120-0444-00
XFMR,TOROID:
80009
120-0444-00
A10U1343
160-2998-05 B010100
B020989
MICRXCT.DGTL:16364 X 8 EPROM,PRSM
80009
160-2998-05
A10U1343
160-2998-06 B020990 MICROCKT.DGTL:16384 X 8 EPROM,PRGM
80009 160-2998-06
A10U2101
155-0022-00
MICRXCT, DGTL:CHANNEL SWITCH
80009 155-0022-00
A10U2202
155-0853-00
MICROCICT, LI NEAR :OPNL AMPL.DUAL
04713
LM358N
A10U2203
156-1642-00
MICROCCT,DGTL:TPL 2-3-2 INP OR/NOR GATE 04713 MC10H105(L OR P)
A10U2204
156-2248-00
MlCROCCT,DGTL:ECL,8 BIT A/D HIGH SPEED
80009 155-2248-00
A10U2205
156-0316-00
M1CR0CCT, DGTL:ECL,Q'JAD 2-INP ECL TO TTL
04713 MC10125L
A10U2206
156-0316-00
MICROCCT.DGTL:ECL,QUAD 2-INP ECL TO TTL
04713
MC10125L
A10U3101
156-1611-00
MICROCKT.DGTL:DUAL D TYPE EDGE-TRIGGERED FF
80009 156-1611-00
A10U31G2
156-1611-00 MICRXCT,DGTL:DUAL D TYPE EDGE-TRIGGERED FF 80009
156-1611-00
A10U3103
156-1611-00
MICROCCT,DGTL:DUAL D TYPE EDGE-TRIGGERED FF 80009
156-1611-00
A10U3104
156-2091-00
MICROCCT,DGTL:QUAD 2-INP POS NAND GATES 01295
SN74ALS0QAN3
A10U3105
156-1611-00
MICRXCT, DGTL: DUAL D TYPE EDGE-TRIGGERED FF 80009 156-1611-00
A10U3106
156-1611-00
MICRXCT,DGTL:DUAL D TYPE EXE-TRIGGERED FF 80009 156-1611-00
A10U3112
156-1707-00
MICRXCT, DGTL:QUAD 2-INPUT NAND GATE 04713 MC7400(NDORJD)
A10U3229
156-1664-00 MI CRXCT.DGTL: SCREENED 01295
SN74ALS574(NP3)
A1OU3230
156-2326-00 MICRXCT, DGTL: 4 BIT COUNTERS W/3 STATE OUT
01295
SN74ALS561AN3J4
A10U3231
156-2326-00 MICRXCT,DGTL:4 BIT COUNTERS W/3 STATE OUT 01295
SN74ALS561AN3J4
A10U3232
156-1664-00 MICROCCT.DGTL:SCREENED 01295 SN74ALS574(NP3)
A10U3233
156-2336-00
MICRXCT. DGTL: LSTTL, 8 BIT MAGTD COMPARATOR
01295 SN74LS684N3
A10U3234
156-1664-00
MICRXCT,XTL:SCREENED 01295 SN74ALS574(NP3)
A10U3235
156-2336-00
MICRXCT,DGTL:LSTTL,8 BIT MAGTD COMPARATOR 01295
SN74LS684N3
A10U3236
156-1664-00
MICRXCT,DGTL:SCREEN ED
01295
SN74ALS574(NP3)
A10U3237
156-1664-00
MICRXCT, X T L : SCREENffi 01295 SN74ALS574(NP3)
A10U3238
156-1664-00
MICRXCT, X T L: SCREENED 01295 SN74ALS574(NP3)
8-3 8
REV HAY 1987
To Next Page
