Commands Listed in Alphabetical Order
Related Commands
HORizontal[:M
AIn]:DELay:MODe
Arguments
<NR3> argument can range from 0 to ≈100 and is the percentage of the waveform
that is displayed left of the center graticule.
NOTE. The upper limit of the waveform position is slightly limited by a value that
is determined from the record length (upper limit = 100 - 1/record length).
Examples
HORIZONTAL:MAIN:POSITION 5.000E+01 sets the horizontal position of the
waveform such that 10 percent of the waveform is to the left of center of the
screen.
HORIZONTAL:MAIN:POSITION? might return :HORI ZONTAL:MAIN:POS ITION
5.0000E+01
, indicating that the horizontal position of the waveform on the
screen is currently set to 50 percent.
HORizontal:MAIn:UNIts
This command sets or returns the units for the horizontal time base. It is
equivalent to setting the HORizontal:MAIn:UNIts:STRing.
Group
Horizontal
Syntax
HORizontal:MAIn:UNIts <STRing>
HORizontal:MAIn:UNIts?
Related Commands
HORizontal:MAIn:UNIts:STRing
Arguments
<STRing> is the time base units string.
Examples
HORIZONTAL:MAIN:UNITS "LUM" sets the time b ase multiplier to 5.5, the units
to lumens and the time base units offset to 2.9.
HORIZONTAL:MAIN:UNITS? might return
:HORIZONTAL:MAIN:UNITS:STR ING “lum”.
HORizontal:MAIn:UNIts:STRing
This command sets or returns the units string for the horizontal time base.
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual 2-259
