Commands Listed in Alphabetical Order
TRIGger:{A|B
}:PULse:RUNT:QUAlify
This command sets or queries the Runt Trigger qualification. This is equivalent
to selec ting Runt Setup from the Trig menu and selecting Occurs or Logic i n
the Trigger i
f Runt drop-down list box.
NOTE. If you use the LOGIc argument, you must specify the channel logic
conditions.
Group
Trigger
Syntax
TRIGger:{A|B}:PULse:RUNT: QUAlify {OCCurs|LOGIc}
TRIGger:{A|B}:PULse:RUNT: QUAlify?
Arguments
OCCurs specifies a trigger if any detectable event occurs.
LOGIc specifies a trigger if the individual channel qualifications meet the logic
patterns and thresholds set by the TRIGger:
Examples
TRIGGER:A:PULSE:RUNT:QUAL IFY OCCURS sets the A trigger to trigger if a
qualifying runt occurs.
TRIGGER:A:PULSE:RUNT:QUAL IFY? might return
:TRIGGER:A:PULSE:RUNT:QUA LIFY OCCURS, indicating that a trigger will
occur if the instrument detects any of the runt qualifications.
TRIGger:{A|B}:PULse:RUNT:THReshold? (Query Only)
This query-only command returns the upper and lower thresholds for the pulse
runt trigger. This command query is equivalent to selecting Runt Setup from the
Trig menu and then viewing the Upper Level and Lower Level settings.
Group
Trigger
Syntax
TRIGger:{A|B}:PULse:RUNT: THReshold?
Related Commands
TRIGger:{A|B}:PULse:RUNT:POLarity, TRIGger:{A|B}:PULse:RUNT:
THReshold:BOTh, TRIGger:{A|B}:PULse:RUNT:THReshold:HIGH ,
TRIGger:{A|B}:PULse:RUNT:THReshold:LOW
2-528 DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual
