Tektronix DPO7000 Series Programmer's Manual

Commands Listed in Alphabetical Order
Syntax
MEASUrement:I
MMed:REFLevel:PERCent:HIGH <NR1>
MEASUrement:IMMed:REFLevel :PERCent:HIGH?
Related Commands
MEASUrement:IMMed:REFLevel:METHod
Arguments
<NR1> is the high reference level, ranging from 0 to 100%. The default high
reference level is 90%.
Examples
MEASUREMENT:IMMED:REFLEVEL :PERCENT:HIGH 95 sets the high reference
level to 95% of HIGH.
MEASUREMENT:IMMED:REFLEVEL :PERCENT:HIGH? might return
:MEASUREMENT:IMMED:REFLEVE L:PERCENT:HIGH 90,indica
ting that the
percentage high reference level is set to 90% of HIGH.
MEASUrement:IMMed:REFLevel:PERCent:LOW
This command sets or queries the percentage (where 100% is equal to HIGH)
used to calculate the low reference level when MEASUrement:IMMed:REFLevel:
METHod is set to Percent. Note that this command affects the results of rise and
fall measurements. This command is equivalent to se
lecting Reference Levels
from the Measure menu and then entering the Percentage Low Ref value.
NOTE. This command affects the results of period, frequency, delay, and all
cyclic measurements.
Group
Measurement
Syntax
MEASUrement:IMMed:REFLevel :PERCent:LOW <NR1>
MEASUrement:IMMed:REFLevel :PERCent:LOW?
Related Commands
MEASUrement:IMMed:REFLevel:METHod
Arguments
<NR1> is the low reference level, ranging from 0 to 100%. The default low
reference level is 10%.
Examples
MEASUREMENT:IMMED:REFLEVEL :PERCENT:LOW 15 sets the low ref
erence
level to 15% of HIGH.
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual 2-375
