Tektronix DPO7000 Series Programmer's Manual

Command Groups
Command
Description
MEASUrement:MEAS<x>:REFLevel:
PERCent:LOW
Sets or r eturns the low level for rise time
(10% level)
MEASUrement:MEAS<x>:REFLevel:
PERCent:MID
<x>
Sets or returns the mid1 or mid2 level for
delay measur
ements
MEASUremen
t:MEAS<x>:SOUrce<x>
Sets or retu
rns the source to measure “from”
or “to” for phase or delay measurements
MEASUrement:MEAS<x>:SOUrce<x>:
SIGType
Sets or returns the type of input signal used
for the specified measurement source for the
specified m
easurement slot
MEASUrem
ent:MEAS<x>:STATE
Sets or re
turns whether the specified
measurement slot is computed and
displayed
MEASUrement:MEAS<x>:STDdev? Returns the standard deviation of values
accumul
ated since the last statistical reset
MEASUre
ment:MEAS<x>:TYPe
Sets or r
eturns the measurement<x> type
MEASUr
ement:MEAS<x>:UNIts?
Returns measurement<x> units
MEASU
rement:MEAS<x>:VALue?
Retur
ns the value of measurement<x>
MEASU
rement:METHod
Sets o
r returns the method used for
calculating reference levels
MEASUrement:NOISe Sets or returns the location of the noise
measurement on the eye waveform
MEASUrement:REFLevel:ABSolute:HIGH Sets or returns the top reference level for
ris
etime
ME
ASUrement:REFLevel:ABSolute:LOW
Se
ts or returns the low reference level for
rise time
MEASUrement:REFLevel:ABSolute:MID<x> Sets or returns the mid1 o r mid2 reference
level for measurements
MEASUrement:REFLevel:METHod Sets or returns the method for assigning high
a
nd low reference levels
MEASUrement:REFLevel:PERCent:HIGH Sets or returns the top reference percent
level for ri se time
MEASUrement:REFLevel:PERCent:LOW Sets or returns the low reference percent
level for ri se time
MEASUrement:REFLevel:PERCent:MID<x> Sets or returns the mid1 or mid 2 reference
percent level for waveform measurements
MEASUrement:SOUrce<x>:SIGType Sets or returns the type of input signal used
for the specified measurement source
MEASUrement:STATIstics:COUNt Clears existing m easurement statistics from
memory
2-42 DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual
