Analyze Wavefor
mData
6. View results.
Snapshot on 1
Period
+Width
Burst W
Rise
+Duty
+Over
High
Max
Amplitude
Mean
RMS
Area
+Edges
+Pulses
: 312.2μs
: 103.7μs
: 936.5μs
: 1.452μs
: 33.23%
: 7.143%
: 9.200 V
: 10.40 V
: 16.80 V
: -5.396 V
: 7.769 V
: -21.58mVs
5
4
Freq
–Width
Fall
–Duty
–Over
Low
Min
Pk-Pk
CycleMean
CycleRMS
CycleArea
-Edges
-Pulses
: 3.203kHz
: 208.5μs
: 1.144μs
: 66.77 %
: 7.143 %
: -7.600 V
: -8.800 V
: 19.20 V
: -5.396 V
: 8.206 V
: -654.6μVs
4
4
Reference Levels
Reference levels determine how time-related
measure
ments are taken. For example, they are
used in calculating rise and fall times.
1. Push Measure.
2. Push More as many times as needed to
selec
t Reference Levels from the r esulting
pop-up menu.
Add Mea-
sureme
nt
Remove
Measur
e-
ment
Indicators
More
Bring
Cursor
s
On Screen
Configure
Cursors
MSO3000 and DPO 3000 Series Oscilloscopes User Manual 107
