Installation
Acquisition System: 50 Ω and 75 Ω
The maximum input voltage: 5 V
RMS
with a peak at ±20 V. For Installation Category I measurements. Not for connection
to Installati
on Category II, III, or IV circuits.
Acquisition
System: Digital Inputs
The maximum input voltage at the input for the digital probe is +30 V to -20 V peak.
Aux In: 1 MΩ
The m aximum input voltage: At the front-panel connector, 300 V
RMS
, Installation Category II; for measurements performed on
circuits di
rectly connected to the low-voltage installation.
CAUTION. T
o ensure proper cooling, keep the sides and rear of the instrument clear of obstructions.
Total Probe Power
:
If the total probe power requirements exceed the available power from the oscilloscope, connect the external AC adapter
(Tektronix part number 119-7465-XX) to the rear-panel Probe Power connector.
Maximum Probe Power Available Per Channel (3 or 5 TekVPI Interfaces):
5 V ± 5%, 50 mA max
., 250 mW max.
12 V ± 10%, 2 A max., 24 W max.
P6139B Pass ive Probe
Maximum tip input voltage: 300 V
RMS
CAT II and DC
Temperature:
Operating: -15 °C to +65 °C ( +5 °F to +149 °F)
Nonoperating: -62 °C to +85 °C ( -80 °F to +185 °F)
Altitude:
Operating: 3.0 km (10,000 ft) maximum
Nonoperating: 15 km (50,000 ft) maximum
Humidity:
Operating: 5% to 95% relative humidity (%RH) up to +30 °C, 5% to 75% RH above +30 °C up to +65 °C. Noncondensing.
Non-operating: 5% to 45% RH above +65 °C up to +85 °C. Noncondensing.
MSO3000 Series Oscilloscope with a P6316 Digital Pro be
Threshold Accuracy: ±(100 mV + 3% of threshold)
Threshold Range: +25 V to –15 V.
Maximum nondestructive input signal to probe: +30 V to -20 V
Minimum signal swing: 500 mV
peak-to-peak
6 MSO3000 and DP O3000 Series Oscilloscopes User Manual
