Get Acquainted w
ith the Instrument
12. Measurement re
adouts show the
selected measurements. You can select
up to four measurements to display at
one time.
A
symbol appears instead of the
expected numerical measurement if a
vertical cli
pping condition exists. Part
of the waveform is outside the range of
the digitizer. The digitizer r ange extends
one division
above and one division
below the screen. To obtain a proper
numerical measurement, turn the vertical
scale and po
sition knobs to bring all of
the waveform within the range of the
digitizer.
13. The auxiliary waveform readouts show
the vertic
al and horizontal scale factors
of the math and reference waveforms.
14. The chann
el readout shows the channel
scale factor (per division), coupling,
invert, and bandwidth status. Adjust with
the Vert
ical Scale knob and the channel
1, 2, 3,or4 menus.
15. For analog channels, the waveform
baseline indicator shows the zero-volt
level o
f a waveform (ignoring the effect
of offset). The icon colors c orrespond to
the waveform colors.
16. For digital channels (MSO3000 Series
only), the baseline indicators point to
the high and low levels. The i ndicator
colors match the color code used on
the physical probe channels. The
D0 indicator is black, the D1 indicator is
brown, the D2 indicator is red, and so on.
40 MSO3000 and DP O3000 Series Oscilloscopes User Manual
