Acquire the Sign
al
6. Push Bit Rate,
and turn multipurpose knob a
to select from the list of predefined bit rates.
Alternately, you can set the bit rate to a
specific value
.Todoso,selectCustom, and
then turn multipurpose knob b to set the bit
rate from 800 bps to 100,000 bps.
Bit Rate
(a)
19.2K bps
7. Push LIN Standard, and turn multipurpose
knob a to select the appropriate standard.
LIN
Standard
v1.x
8. Push Includ
e Parity Bits with Id to select
whether or not to include parity bits.
Include
Parity Bits
with Id
On|
Off
FlexRay Bu
s
To acquire data from a FlexRay bus, you need to also set up these items:
1. If you selected FlexRay, push Define Inputs
and the appropriate side menu choices.
Bus
FlexRay
Define
Inputs
Thresholds
786 mV
22.0 mV
Bit Rate
10000000
B1 Label
FlexRay
Bus
Display
Event
Table
2. Turn multipurpose knob a to select the
channel connected to the FlexRay bus
source.
FlexRay
Input
(a) 1
3. Push the appropriate side menu buttons for
FlexRay Channel Type and Polarity.
FlexRay
Channel
Type
A
B
4. Push Thresholds to set the Channel
Thresholds. Turn multipurpose knob a to set
the high threshold level. Turn m ultipurpose
knob b to set the low threshold level.
Thresh-
olds
786 mV
22.0 mV
MSO3000 and DPO 3000 Series Oscilloscopes User Manual 63
