Acquire the Sign
al
2. Push MagniVu and select On.
D15 – D0
On/Off
Thresholds Label MagniVu
On |
Off
Height
S |ML
Quick Tips
If you think you need more timing resolution, turn on MagniVu to increase the resolution.
MagniVu is always acquired. If the oscilloscope is in a stopped state, you can turn on MagniVu and still get the resolution
without ta
king another acquisition.
The seria
l bus features do not use data acquired in M agniVu mode.
MSO3000 and DPO 3000 Series Oscilloscopes User Manual 69
